We do not – We found the leverage curve of our bikes leaves the shock very tunable. We have successfully set up riders from 95 lbs. to well over 230 lbs.

Any guide or bashguard with ISCG-05 tabs is compatible with the Rail29.

You can – You will need to order the shock directly from Fox and ensure you purchase the correct tune for our bikes. This is important to maximize how awesome your Revel can be! Fox has a tune guide for our bikes on file. Unfortunately due to our agreement with Fox, you are not able to buy Fox suspension directly from Revel unless is ships on your new bike.

22 ounces is the sweet spot – When using a side-loading water bottle cage, our frames fit a standard Revel 22-ounce water bottle. With a hands-free cap, these bottles are the best option around. Insulated bottles or larger sizes will need to be physically tested for clearance. You can also use Fidlock bottles for extra space!

52mm Chainline

36t Round / 34t Oval

Like this – Our in-house builders prefer to cross the derailleur cable over the rear brake cable. That being said, there is no wrong way; You can run the brake line and derailleur housing to cross under the bottom bracket or not. Just be sure to leave enough slack under the bottom bracket so that the bike can fully cycle through its travel without binding. A good rule of thumb is for the cables to be level with the teeth of your chainring.

Yes, we have touch-up paint for select colorways. But if we don't have exactly what you're looking for, we have found luck using good, old-fashioned nail polish.

Yes, the Rail29 is compatible with coil shocks from most major manufacturers.
