Overview

One bike to rule them all

The new Rascal redefines confidence and versatility and is engineered for speed and agility, thriving on any single track ahead. This mischievous marvel rocks 130mm of rear travel and is eloquently balanced with a perfect 140mm fork up front and is future proofed with UDH compatibilities. The soul of the Rascal comes to life as the CBF suspension engages with our modern geometry and same perfected kinematics. With an all new carbon layup, this bike is fast, mighty capable mountain and ready to slash any berm, drop any rock, climb any peak, and shred any descent. Want to learn more? Check out our FAQ or contact us directly!

Key Attributes

130mm
Rear Travel
29"
Wheel
140mm
Front Travel
Thermoset Carbon Fiber
Frame Material

The CBF™ focuses the center of curvature in a very finite area on the chainline/top of the chainring, pointing the pedaling forces directly where you want them.

Learn More »

Build Your Bike

Build your bike below to see pricing and availability. Prefer to only see what is in-stock? Check out our Shop In-Stock page!

$100.00

Rascal

Build Specs

SRAM GX
$5,999
SRAM GX Transmission*
$6,499
Shimano XT
$6,999
SRAM X0 Transmission
$7,999
SRAM XX Transmission
$10,499
FrameRevel Rascal 29″ 130mm TravelRevel Rascal 29″ 130mm TravelRevel Rascal 29″ 130mm TravelRevel Rascal 29″ 130mm TravelRevel Rascal 29″ 130mm Travel
ForkRockShox Lyrik Select + 140mmRockShox Lyrik Select + 140mmFox Float 36 Factory Series 140mmRockShox Lyrik Ultimate 140mmRockShox Lyrik Ultimate 140mm
ShockRockShox Super Deluxe Ultimate RockShox Super Deluxe Ultimate Fox Float X Factory SeriesRockShox Super Deluxe Ultimate RockShox Super Deluxe Ultimate
WheelsCrank Bros. Synthesis Enduro Rims
Industry Nine 1/1 Hubs
Crank Bros. Synthesis Enduro Rims
Industry Nine 1/1 Hubs
Crank Bros. Synthesis Enduro Rims
Industry Nine 1/1 Hubs
(*upgrade available)
Crank Bros. Synthesis Enduro Rims
Industry Nine 1/1 Hubs
Revel RW30 V2 Rims
Industry Nine Hydra Hubs
HeadsetCane Creek 40-seriesCane Creek 40-seriesCane Creek 40-seriesCane Creek 40-seriesCane Creek 40-series
TubelessStans No tubes Single shots x2Stans No tubes Single shots x2Stans No tubes Single shots x2Stans No tubes Single shots x2Stans No tubes Single shots x2
TiresContinental Kryptotal 29" x 2.4" Trail Soft Front, Continental Xynotal 29" x 2.4" Trail Endurance RearContinental Kryptotal 29" x 2.4" Trail Soft Front, Continental Xynotal 29" x 2.4" Trail Endurance RearContinental Kryptotal 29" x 2.4" Trail Soft Front, Continental Xynotal 29" x 2.4" Trail Endurance RearContinental Kryptotal 29" x 2.4" Trail Soft Front, Continental Xynotal 29" x 2.4" Trail Endurance RearContinental Kryptotal 29" x 2.4" Trail Soft Front, Continental Xynotal 29" x 2.4" Trail Endurance Rear
BarRaceFace Aeffect R 35
780 x 20mm Rise
RaceFace Aeffect R 35
780 x 20mm Rise
RaceFace Aeffect R 35
780 x 20mm Rise
RaceFace NEXT R 35
800 x 20mm Rise
RaceFace NEXT R 35
800 x 20mm Rise
GripsTrail 1 Farlow Gap Grip - BlackTrail 1 Farlow Gap Grip - BlackTrail 1 Farlow Gap Grip - BlackTrail 1 Farlow Gap Grip - BlackTrail 1 Farlow Gap Grip - Black
StemRaceFace Aeffect R 35 x 40mm RaceFace Aeffect R 35 x 40mmRaceFace Aeffect R 35 x 40mmRaceFace Aeffect R 35 x 40mm RaceFace Aeffect R 35 x 40mm
PostCrank Brothers Highline 7
SM (31.6mm x 125mm)
MD (31.6mm x 150mm)
LG (31.6mm x 170mm)
XL/XXL (31.6mm x 200mm)
Crank Brothers Highline 7
SM (31.6mm x 125mm)
MD (31.6mm x 150mm)
LG (31.6mm x 170mm)
XL/XXL (31.6mm x 200mm)
Bike Yoke Revive 2.0
SM (31.6mm x 125mm)
MD (31.6mm x 160mm)
LG (31.6mm x 185mm)
XL/XXL(31.6mm x 213mm)
Bike Yoke Revive 2.0
SM (31.6mm x 125mm)
MD (31.6mm x 160mm)
LG (31.6mm x 185mm)
XL/XXL(31.6mm x 213mm)
Bike Yoke Revive 2.0
SM (31.6mm x 125mm)
MD (31.6mm x 160mm)
LG (31.6mm x 185mm)
XL/XXL(31.6mm x 213mm)
Dropper LeverCrank Brothers Highline Dropper RemoteCrank Brothers Highline Dropper RemoteRevel - Wolftooth ReMoteRevel - Wolftooth ReMoteRevel - Wolftooth ReMote
SaddleSDG Radar Lux-Alloy SDG Radar Lux-Alloy SDG Radar Lux-Alloy SDG Radar Lux-Alloy SDG Radar Lux-Alloy
BrakesSRAM Code R SRAM Code Bronze StealthShimano XT 4 PistonSRAM Code RSCSRAM Code Ultimate Stealth
RotorsSRAM Centerline 6-Bolt 180mm front & rearSRAM Centerline 6-Bolt 180mm front & rearShimano Rotor XT RT86 6-Bolt 180mmSRAM HS2 180mm front & rearSRAM HS2 180mm front & rear
ShifterSRAM GX EagleSRAM AXS Shifter PodShimano XT M8100 12spdSRAM AXS Shifter PodSRAM AXS Shifter Pod
Rear DerailleurSRAM GX EagleSRAM GX ETShimano XT M8100SRAM X0 ETSRAM XX ET
ChainSRAM GX EagleSRAM GX ET T-TypeShimano XT M8100 12spdSRAM GX ET T-TypeSRAM XX ET T-Type
CassetteSRAM GX Eagle 10-52SRAM GX ET T-TypeShimano XT M8100 10-51 12spdSRAM X0 ET T-TypeSRAM XX ET T-Type
CranksetSRAM GX Eagle alloy DUB 170mm 32t SRAM GX Eagle T-Type 170mm 32tShimano XT M8120 170mm 32tSRAM X0 Eagle T-Type 170mm 32tSRAM XX Eagle T-Type 170mm 32t
Bottom BracketSRAM DUB WIDE BSASRAM DUB WIDE BSAShimano XT MT800SRAM DUB WIDE BSASRAM DUB WIDE BSA
Seat CollarRevel 34.9mm DiaRevel 34.9mm DiaRevel 34.9mm DiaRevel 34.9mm DiaRevel 34.9mm Dia
**Specifications subject to change without notice****Specifications subject to change without notice**
*Only available at your local Revel dealer.
**Specifications subject to change without notice****Specifications subject to change without notice****Specifications subject to change without notice**

The Revel Rascal got a lot right with the first release and the new Rascal nearly perfects this winning trail bike formula. It can handle almost any descent yet it still climbs like an XC bike, and does so with confident style.Read more...

It’s also an outstanding technical climber, and remarkably balanced and intuitive in a wide range of situations. It’s an easy bike to recommend to a whole lot of folks, and one of the more impressive takes on a short-ish travel do-it-all bike I’ve ridden to date. Read more...

It balances traction and efficiency on the climbs, as well as control and capability on the descents, and puts it all in a package that lives up to the name, "Rascal." Read more...

S M L XL XXL
S M L XL XXL
RIDER HEIGHT (In.) 5'1" - 5'6" 5'5" - 5'10" 5'9" - 6'1" 6'0" - 6'4" 6'3" - 6'8"
RIDER HEIGHT (cm) 155 - 168cm 165 - 178cm 175 - 185cm 182 - 193cm 190-203cm
EFFECTIVE TOP TUBE LENGTH 582mm 603mm 625mm 650mm 678mm
SEAT TUBE LENGTH 385mm 415mm 445mm 475mm 505mm
SEAT TUBE ANGLE (EFFECTIVE/ACTUAL) 76°/71° 76°/71° 76°/71° 76.5°/72° 77°/72°
CHAIN STAY LENGTH 436mm 436mm 436mm 436mm 436mm
BOTTOM BRACKET DROP 34.2mm 34.2mm 34.2mm 34.2mm 34.2mm
BOTTOM BRACKET HEIGHT 345mm 345mm 345mm 345mm 345mm
HEAD TUBE ANGLE 65.5° 65.5° 65.5° 65.5° 65.5°
WHEEL BASE 1175mm 1198mm 1222mm 1256mm 1293mm
HEAD TUBE LENGTH 95mm 101mm 110mm 129mm 145mm
AXLE TO CROWN 551mm 551mm 551mm 551mm 551mm
FORK OFFSET 44mm 44mm 44mm 44mm 44mm
TRAIL 123mm 123mm 123mm 123mm 123mm
STACK 604mm 610mm 618mm 635mm 650mm
REACH 431mm 451mm 471mm 498mm 528mm
STANDOVER 717mm 720mm 728mm 742mm 760mm
WHEEL SIZE
29”
FRONT TRAVEL
140mm min / 150mm max
REAR TRAVEL
130mm
SHOCK SPEC
210mm x 50mm
25.0mm x 8 Mounting Hardware Spec
HUB SPACING
Boost 148mm rear / 110mm front
AXLE SPEC
SEATPOST DIAMETER
31.6mm, 34.9mm Seat Collar
SEATPOST INSERTION DEPTH
300+mm ALL SIZES
BEARINGS
BOLU Bearings 6902 V2RD 15x28x7mm (QTY 6)
BOLU Bearings 6801 V2RD 12x21x5mm (QTY 4)
REAR BRAKE
Post Mount: 180mm direct / 203mm max
TIRE CLEARANCE
29” x 2.6” (rear)
BOTTOM BRACKET
Threaded (73mm English threaded)
MAX CHAINRING
36T Round / 34T Oval, 55mm Chainline
TAPERED HEADTUBE
IS42 upper / IS52 Lower
BOTTLE BOSSES
2 Sets of bosses. 1 set located along top of down tube. 1 set located along bottom of down tube. Size XXL has an additional set underneath the top tube
COLORS
Ponyboy / Pinot Gnar
SIZES
S / M / L / XL / XXL
FRAME WARRANTY
Lifetime Warranty - View Details
title
val
LEVERAGE RATIO
ANTI-RISE
ANTI-SQUAT

The Details

Design Features

Rascal Ponyboy

SRAM UDH

SRAM's UDH derailleur hanger has been incorporated to keep the Rascal compatible with the latest and greatest drivetrain technologies

Rascal Ponyboy

Threaded Bottom Bracket

Simple, easy, straightforward, and standard. We believe threaded BBs are key to any bike for all the practical reasons.

Premium Hardware

The all new Rascal shares the effective and simple hardware design found on Ranger and Rail29 providing increased frame stiffness, more clearance, easier maintenance, and an even quieter ride.

Rascal Ponyboy

Integrated Headset

Simple, easy maintenance with no need for fancy tools. All Revels have integrated headsets with carbon bearing seats for a quiet ride and easy replaceability.

Rascal Pinot Gnar

CBF™ Suspension

The Rascal utilizes the CBF™ suspension system that focuses the pedaling forces above the chainring throughout the range of travel, propelling the bike forward through challenging terrain.

Rascal Ponyboy

Fully Guided Internal Tubing

Simple, quiet cable routing! Fully guides internal tubes make maintenance and replacing cables a dream.

Debris Guard

Keep those lower pivots and link clean and clear with our Debris Guard. Included with every Rascal frame.

Support

We do not – We found the leverage curve of our bikes leaves the shock very tunable. We have successfully set up riders from 95 lbs. to well over 230 lbs.

We only recommend the Push ELEVENSIX coil shock.

The shock size is 210x50mm. The mounting hardware size is 25x8mm.

The Rascal was designed to use a 140mm fork with a 44mm offset and an axle-to-crown length of 547-551mm. You may use a 150mm fork with a maximum axle-to-crown length of 561mm.

No you cannot and while we love experimenting and innovation, doing so will void the warranty.

30% is the recommended amount of sag to run on the Rascal. Start with 30% then you can adjust +/- 5% for a slightly softer or firmer ride.

RockShox Super Deluxe Shock has 2 spacers. Rockshox Lyrik Fork has 1 volume spacer. Fox Float X has a 0.4 volume spacer. Fox Float 36 fork has 2 volume spacers.

No we do not recommend doing this. The Rasal was designed to be ridden as a full 29er and performs at its best in this configuration.

The Rascal uses a BSA 73mm threaded bottom bracket.

The Rascal features ISCG-05 tabs. This is a common mounting standard for chainguides and bash guards that you can find from great companies like MRP, OneUp, and E13.

36T ROUND / 34T OVAL.

Maximum rear tire size is 29x2.6.

31.6mm seatpost diameter. 34.9mm seat clamp diameter.

All sizes have a max seatpost insertion depth of 300mm+.

Minimum Rotor size is 180mm. Maximum rotor size is 203mm.

Yes! Following feedback from the original Rascal, we are excited to have a lower link debris guard included with every Rascal frame.

Yes, the Rascal is equipped with UDH to keep it compatible with the latest and greatest drivetrain technologies.

IS52/IS42mm Integrated headset.

The rear hub spacing is 148mm, also known as ""Boost". The axle is 12mm diameter, 177mm long, 1.0mm thread pitch.

You can – You will need to order the shock directly from Fox and ensure you purchase the correct tune for our bikes. This is important to maximize how awesome your Revel can be! Fox has a tune guide for our bikes on file. Unfortunately due to our agreement with Fox, you are not able to buy Fox suspension directly from Revel unless is ships on your new bike.

Sizes Small through XL frames will fit one bottle within the front triangle and a second bottle on the underside of the downtube. All sizes will clear a 22oz bottle. Larger sizes will have clearance for 26oz bottles. The XXL size can fit a 3rd 22oz bottle on the underside of the toptube

55mm Chainline

Yes! Head to Revel's gear store to find all paint colors available today to touch up any dings you've collected along the way.

Shock mount hardware and chainline are affected between original Rascal and New Rascal, but are easily adapted to work with each other. When you buy a New Rascal frame from Revel it includes a shock so you are all set there, but if you are transferring a shock from the Original Rascal to the New Rascal then please note the mounting hardware has been updated from 22.2x8mm to 25x8mm. You will need a 25x8mm hardware kit. These are specific to the brand of shock you have and are easily obtainable online or from your local bike shop. this is a quick install by a bike mechanic. Minimum chainline on the Original Rascal was 52mm and now minimum chainline on the New Rascal is 55mm. Most cranksets designed for a 52mm chainline can be adapted to 55mm by installing a new chainring with a different offset. This is commonly a 0mm offset, but some brands do it differently. WolfTooth Components is a great source for information and purchasing these chainrings. Please call Revel Customer Service if you have more questions about this.

Torque Specifications
Pivot #1
15 Nm
Apply grease to axle shaft (DO NOT apply grease to threads)
Pivot #2
15 Nm
Apply grease to axle shaft (DO NOT apply grease to threads)
Pivot #3
15 Nm
Apply grease to axle shaft (DO NOT apply grease to threads)
Front triangle and rear triangle must be assembled before upper link is connected to rear triangle.
Pivot #4
10 Nm
Pivot #5
15 Nm
Apply grease to axle shaft (DO NOT apply grease to threads)
Front triangle and rear triangle must be assembled before upper link is connected to rear triangle.
Rear Shock Bolt
15 Nm
Apply titanium anti-seize to threads on rear shock bolt.
Forward Shock Bolt
10 Nm
Revel UDH Rear Axle
13 Nm
Seat Clamp
5 Nm
SRAM Universal Derailleur Hanger
25nm
NOTE: UDH Hanger is left-hand threaded
Cable Clamp
2nm
Required Tools for Basic Service
» 1x 4mm Hex Key
» 1x 5mm Hex Key
» 1x 6mm Hex Key
» 1x 8mm Hex Key
» Torque Wrench
» Grease
» Titanium Anti-Seize Compound
» *Bearing Puller (Slide Hammer)
-12mm Bearing Collet
-15mm Bearing Collet
» *Bearing Press
-12mm ID Bearing Drift (Ensure largest diameter on drift measures less than or equal to 21mm) [ Used on Pivot 1, Pivot 2, Pivot 3 & Pivot 5 ]
- 15mm ID Bearing Drift (Ensure largest diameter on drift measures less than or equal to 24mm) [ Used on Pivot 4 ]
» *If performaning full bearing replacement
Part Number Description Qty.
6 310-10021-0063 Pivot #1/#2 Axle 2
7 310-10021-0060 Pivot #1/#2/#4 Axle Nut 3
8 100-BEA21-0001 BOLU Bearing 6902 P1/P2/P4 6
9 310-10021-0058 Pivot #1/#2/#4 Pivot Spacer 5
10 310-10021-0062 Pivot #1/#2 Axle Spacer 2
11 310-10021-0064 Pivot #3/#5 Axle Nut 4
12 310-10021-0066 Pivot #3/#5 Axle 4
13 310-BEA18-0106 BOLU Bearing 6801 P3/P5 4
14 310-10021-0088 Pivot #3/#5 Axle Spacer 4
15 310-10021-0091 Pivot #4 Axle Collet 1
16 310-10021-0061 Pivot #4 Axle Spacer 1
17 310-10021-0089 Pivot #4 Collet Wedge 1
18 Pivot #4 Socket Head Cap Screw 1
19 310-10021-0106 Forward Shock Mount Bolt 1
20 310-10021-0105 Forward Shock Mount Axle 1
21 310-10021-0077 Rear Shock Bolt 1
22 100-DER19-0006 Sram UDH Hanger 1
23 300-axl21-0003 177mm UDH Rear Axle 1
24 320-10021-0017 Front Triangle Downtube Protector 1
25 320-10021-0018 Revel 29160 Chainstay Protector 1
26 310-10021-0068 BB Cable Clamp 1
27 Socket Head Cap Screw M5X0.8X14 5
28 310-10021-0092 Pivot #4 Hardware Washer 1
»   For detailed view and part information on specific pivots, please download the tech manual.
»    Ensure all bolts are torqued to spec listed in this manual and on bolt head.
»   All bolts are right hand threaded but have hex profiles on either end. If turning the bolt from the threaded side, turning counter clockwise will tighten the bolt
»   Bolts come with Nylock patch installed. This serves the function of thread looker and can be reused for multiple installations. Verify condition of patch before assembly. If patch looks worn or damaged add Blue Loctite 243.
»   It is easier to tighten linkage assembly to torque once it has been fully assembled. Similarly it is easiset to break bolts free when linkage is fully assembled.
»   All images shown in exploded views of pivots correspond to exploded view on Page 4 of Tech Manual.
